LIFT AMBARCATIUNE BASTA BOATLIFTS - GALVANIZED STEEL - 4536 KG / 135 CM

• Lift Capacity 4536 kg

• Lifting Range 135 cm
• Minimum Water Depth 69 cm
• Frame Material Galvanized Steel
• Frame Length 394 cm
• Frame Width 297 cm
• Frame Weight 586 kg
• No. of legs needed 4 (2.5”)
• Bunk Length 437 cm
• No. of bunks 8
• Shipping Weight 907 kg
• No. of Hydraulic Cylinders 2
• Standard Leg Length 122 cm
• Standard Hose Length 69 cm
• Mono-Crystal Solar Charger 12 Watt
• Remote Control Transmitters 2

Heavy Duty, yet easy to assemble.
Spend less time launching and more time on the water with the 10k galvanized steel free-standing boat lift. Steel is robust and long lasting. Its rigid properties are preferred for Class 2 and Class 3 sized boats, and it is also ideal for deep-water sites.
No latches, cables or levers are needed to secure the raised lift. Basta Boatlifts’ patented Over-Center™ gravity locking design with Balanced Load™ H-frame technology uses gravity to hold the raised lift in place without the possibility of drifting down.

No Weld Cylinders                   Delrin® Bushings
Delrin® Bushings allow pivot points to be tighter and operate more smoothly. High strength polymer construction eliminates metal-to-metal contact reducing electrolysis, extending the life of the boat lift.
No weld cylinders! Basta Boatlifts uses cylinders made from corrosion resistant aluminum and have no welds. Eliminating welds increases strength and reduces the possibility of corrosion.

• Stainless steel cylinder fittings & hose ends

• Duplex-bonded synthetic hydraulic hoses

• Time-tested full length rotating bunks to protect your hull

• Stainless steel hardware

• Hydraulic power pack housed in a strong and attractive white fiberglass dock box with stainless steel hardware and lockable lid

• Spartan Power battery cables

• Two wireless remote control key fobs

• Manual control switches in power box

• 12 Watt solar panel securely mounted on top of the fiberglass box. Can be remotely installed or used with a simple “float” charger

• Hydraulics that use a special long-life, environmentally friendly fluid
